Key features
Technical Features
| Turntable diameter | 1650 mm (std) / 1800 mm (opt) |
| Max load weight | 100 kg (DW), 150 kg (DW-C) |
| Turntable speed | 5–12 rpm |
| Carriage up-down speed | 1.5–5.5 m/min |
| Useful mast height | 2400 mm (std) / 2800 or 3100 mm (opt) |
| Pneumatic presser height | 1050–2100 (H=2400), 1050–2500 (H=2800), 1050–2800 (H=3100) |
| Mechanical presser height | 400–2100 (H=2400), 400–2500 (H=2800), 400–2800 (H=3100) |
| Film carriage type | FR, PDS |
| Film stretch | Adjustable from control panel |
| Film pre-stretch | n.a. (FR), fixed 250% std (PDS) |
| Forklifting | Front and rear |
| Power supply voltage | 230 V 1Ph |
| Power supply frequency | 50/60 Hz |
| Installed power | 1.5 kW (FR) / 1.9 kW (PDS) |
| Max reel dimensions | 500 × 300 mm |
| Max reel weight | 20 kg |
| Film thickness | 17–35 μm |
